12 Ton Battery Locomotive

The 12 ton battery locomotive could be the normal type or the anti-explosion one it could pull about 90~100 ton ores which it widely used in those middle or large mines.

CJY10 Ton Underground Mining Trolley Locomotive

12 Ton Battery Locomotive could be the normal type or the anti-explosion one it could pull about 90~100 ton ores which it widely used

 in those middle or large mines.

The locomotive is applied of speed control of IGBT chopping wave type or VF type. Its main features include: high starting torque

strong traction force and carrying capacity energy efficiency and low maintenance workload. It is applied of both air damping and

electric braking functions and can work safely. Two-end driver’s cabs can be equipped with good rearview. The locomotive is suitable

 for coal mines with high gas or metal mines and tunnel.



Video of the 12 ton locomotive

The Introduction of Different battery for locomotive:

There are three types of locomotive power supply options: ordinary lead-acid battery for locomotive maintenance-free battery for locomotive

and lithium battery for locomotive.

Ordinary lead-acid power supply needs to be charged with acid and water. The charging time is up to 8-10 hours the working time is 8 hours

and the service life is 1-2 years.

The maintenance-free power supply requires no water for charging so the maintenance is simple. The charging time also takes about 8-9 hours

the working time is 8 hours and the service life is 1-2 years.

Lithium power supply does not need to add water and is maintenance-free. It can be fully charged in 2-3 hours working time is more than 8 hours

 and the service life is 5-8 years.



locomotive battery


Hot Tags: 15 ton battery locomotive, China, manufacturers, suppliers, factory, customized, price
Model CTY12/679G(B)
Weight 12t
Track gauge 600762 or 900mm
Traction force 16.48kN
Max traction force 29.43kN
Speed 8.7km/h
Battery device voltage 192V
capacity 560Ah
Motor power 22Kw x 230Kw x 2
Dimensions Length 5100mm
width 10501212 or 1350mm
Height 1800mm
Wheel base 1220mm
Wheel diameter Φ680mm
Min turn radius 10m
Controller method Resistance,IGBT or frequency
Brake method Mechnical,Electric,Ac frequency
