IGBT Controller for Mine Locomotive DC Chopper Speed Control for locomotive

The IGBT controller also named as DC Chopper Speed Control for locomotive it got 2 type the normal type and the explosion-proof type the explosion-proof type is usually applied in the place with great moist or the place with explosion gas.

CJY10 Ton Underground Mining Trolley Locomotive

The IGBT controller also named as DC Chopper Speed Control for locomotive it got 2 type the normal type and the explosion-proof type the explosion-proof type is usually applied in the place with great moist or the place with explosion gas.

The IGBT Controller has a simple circuit no runaway phenomenon and rarely replaces contacts which greatly reduces the maintenance workload. Using this device the locomotive starts smoothly the speed is uniform the overload capacity is strong the electric energy is saved by about 30% and the service life of the battery is prolonged. It is deeply welcomed by drivers maintenance personnel and grassroots management personnel.

Model    ZBT- 130/48   (2.5Ton battery locomotive) ZBT- 2×120/96 (5Ton battery locomotive) ZBT- 2×150/140 (8Ton battery locomotive) ZBT- 2×150/192 (12T battery locomotive) ZKT- 2×100/250(Trolley locomotive) ZKT- 2×100/550 (Trolley locomotive)
Specification
Rated Voltage 48 96 140 192 250V 550V
Range of Voltage 33-53 62-130 91-189 124-260 175-300 385-660
Rated Current 130A 120A×2 150A×2 150A×2 100A × 2
Max Current 260A(Short-term work) 240A×2(Short-term work) 300A×2(Short-term work) 300A×2(Short-term work) 2×200A
Operating Frequency 800Hz - 1KHz 800Hz-2KH
Pressure regulation ratio 0 - 100%
Given voltage 0 - 5V
