YVF55Q AC Motor For 14 Ton Mine Trolley Locomotive

YVF45Q AC Motor is used on China 14 ton trolley electric locomotive the model type is CJY14/679GP. It has features of simple structure energy conservation maintenance-free smooth operation capability and high efficiency.

CJY10 Ton Underground Mining Trolley Locomotive

YVF55Q (380/220) Mining general type AC traction motor

This motor is used in the China Mine Trolley locomotive of 14 ton it has the big traction power.

The motor adopts a fully enclosed self-cooling structure a single extension shaft the shaft extension is cylindrical or conical and the locomotive axle is driven by a coupling or gear transmission.

We are a professional manufacture of the mine locomotive DCAC motors we could design the motors according to your need.




Hot Tags:


YVF-55Q AC motor Model YVF-55Q
Working rating S2-60min
Power kw 55
Voltage v 400
Current A 100.7
Frequency Hz 65.8
Speed of rotation r/min 1300
Insulation grade F or H
Level of protection Ip54
Weight kg 530
