The ZWY80 wheel scraper mucking loader is designed for superior maneuverability in narrow and confined underground spaces. It features a compact design, a powerful engine, and a tight turning radius, allowing it to easily navigate even the most challenging environments.
ZWY80 Wheel Scraper Mucking Loader
The ZWY80 wheel scraper mucking loader is designed for superior maneuverability in narrow and confined underground spaces. It features a compact design, a powerful engine, and a tight turning radius, allowing it to easily navigate even the most challenging environments.
Outline Drawing of crawler mucking loader
| Wheel scraper mucking loader parameter table | ||||
| Index | Unit | ZWY-1.7-80 | ZWY-1.8-120 | |
| Loading capacity | M3/H | ≤80 | ≤120 | |
| Total weight | KG | 5800±200 | 6200±200 | |
| Wheelbase | MM | 1600 | 1780 | |
| Gauge | MM | 1460/1460 | 1640/1480 | |
| Minimum turning radius | R | ≤5 | ≤6 | |
| Minimum ground clearance | MM | 190 | 190 | |
| Digging width | MM | 3200 | 3500 | |
| Digging depth | MM | 450 | 540 | |
| Digging height | MM | 2900 | 3100 | |
| Digging distance | MM | 1650 | 1750 | |
| Unloading height(customizable) | MM | 1700 | 1900 | |
| Unloading distance(customizable) | MM | 1900 | 3000 | |
| Gradeability | ° | ±12(Hard ground) | ±12(Hard ground) | |
| Conveyor belt speed | M/S | 0.54 | 0.54 | |
| Total motor power | KW | 30(Double 15) | 30(Double 15) | |
| Main motor power | KW | 30(Double 15) | 30(Double 15) | |
| Electric drum power | KW | / | / | |
| Fan power | KW | 0.8 | 0.8 | |
| Walking speed | KM/H | High 5.5,low 3 | High 5.5,low 3 | |
| Rated operating pressure | Mpa | 15 | 15 | |
| Dimensions | L | MM | 6600±50 | 7500±50 |
| W | MM | 1750±50 | 1850±50 | |
| H | MM | 1800±50 | 2000±50 | |
| Adapation dimension | M | 2.4*2.4 | 2.8*2.8 | |
