The locomotive is applied of speed control of IGBT chopping wave type or VF type. Its main features include: smooth starting, stable operation, small dimension, short wheel base, quick and reliable braking effect by means of braking shoes; simple structure for easy maintenance and reliable locomotive operation performance. It is an ideal type for tr8nspod8tion or transfer service in medium-small mines.
Battery-powered locomotives are designed for horizontal rail transport especially in mines and enclosed spaces. They are also intended for use in potentially explosive environment with coal dust and methane in volume up to 1.5 %. They can work on slopes of rail lines up to 35‰ , with track gauge from 500 to 1060 mm, at ambient temperatures from -20°C to +40°C.
Technical Specification
| Model | CTY2.5/6、7、9G(B) | ||
| Dead weight | 2.5t | ||
| Track gauge | 600、762 or 900mm | ||
| Traction force | 2.55kN | ||
| Max traction force | 6.13kN | ||
| Speed | 4.54km/h | ||
| Battery device | Lithium battery | 51.2v 300ah | |
| Lead acid battery | 48V330AH | ||
| Motor power | 3.5kW×1 | ||
| Dimensions | Length | 2330mm | |
| width | 914、1076 or 1212mm | ||
| Height | 1550mm | ||
| Wheelbase | 650mm | ||
| Wheel diameter | Φ460mm | ||
| Min turn radius | 5m | ||
| Controlling way | Resistance or IGBT chopper | ||
| Brake way |
Mechanical brake | ||
