High quality 4 ton mining diesel dumper truck

This high quality 4 ton mining diesel dumper truck is powered by a robust diesel engine that delivers reliable performance and high torque. The spacious cab provides a comfortable and safe working environment for the operator, while the durable dump bed can withstand the harshest mining conditions. This high quality 4 ton mining diesel dumper truck is ideal for a wide range of mining applications, including hauling rock, ore, and other materials.

CJY10 Ton Underground Mining Trolley Locomotive

High quality 4 ton mining diesel dumper truck

This high quality 4 ton mining diesel dumper truck is powered by a robust diesel engine that delivers reliable performance and high torque. The spacious cab provides a comfortable and safe working environment for the operator, while the durable dump bed can withstand the harshest mining conditions. This high quality 4 ton mining diesel dumper truck is ideal for a wide range of mining applications, including hauling rock, ore, and other materials.

Video



Shipment and site details




shipment and site 5.jpg

shipment and site 3.jpg

shipment and site 7.jpg

shipment and site 6.jpg



Hot Tags: dumper truck  |   mining truck  |   battery locomotive  |   trolley locomotive  |   rock loader  |   electric rake winch  |
Load capacity4 ton5 ton6 ton8 ton10 ton12 ton
Fuel typeDieselDieselDieselDieselDieselDiesel
Motor modelChangchai 490Yunnei 490Yunnei 490Yunnei 4102Yunnei 4102Yunnei 4105
Motor power46KW (63 HP)46KW (63 HP)46KW (63 HP)81KW (110 HP)81KW (110 HP)90KW (122 HP)
Gearbox model530 (12-speed)530 (Twelve high and low speed gears)530 (Twelve high and low speed gears)546 (Twelve high and low speed gears)546 (Twelve high and low speed gears)545 (Twelve high and low speed gears)
Rear axleSL176TDF1069DF1069DF1092DF1092DF1098D
Front axleSL175TSL178SL178SL2059SL2059SL450
Braking systemAir BrakeAir BrakeAir BrakeAir BrakeAir BrakeAir Brake
Rear wheel track1450mm1630mm1630mm1800mm1800mm2150mm
Front wheel track1450mm1630mm1630mm1800mm1800mm1900mm
Wheelbase
2400mm2400mm2620mm2620mm2650mm
Chassis
Main beam: Height 120mm * Width 60mm * Thickness 8mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 6mm
Main beam: Height 120mm * Width 60mm * Thickness 8mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 6mm
Main beam: Height 120mm * Width 60mm * Thickness 8mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 8mm
Main beam: Height 140mm * Width 60mm * Thickness 10mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 8mm
Main beam: Height 200mm * Width 60mm * Thickness 10mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 8mm
Unloading methodRear unloadingRear unloading, double 800mm hydraulic jacksRear unloading, double 800mm hydraulic jacksRear unloading, double 110mm hydraulic jacksRear unloading, double 110mm hydraulic jacksRear unloading, double 110mm*950mm hydraulic jacks
Front tire model650-16 steel wire tire700-16 mining tire700-16 mining tire750-16 mining tire825-16 mining tire825-16 mining tire
Rear tire model700-16 steel wire tire (dual)700-16 mining tire (double tire)700-16 mining tire (double tire)750-16 mining tire (double tire)825-16 mining tire (double tire)825-16 mining tire (double tire)
D imensionsL*W*H : 3950mm*1450mm*1330mmL*W*H : 4900mm*1630mm*1400mmL*W*H : 4900mm*1630mm*1400mmL*W*H : 5200mm*1800mm*1750mmL*W*H : 5400mm*1800mm*1750mmL*W*H : 5100mm*2150mm*1750mm
Cargo dimensionsL*W*H : 2400mm*1330mm*450mmL*W*H : 3100mm*1600mm*500mmL*W*H : 3100mm*1600mm*500mmL*W*H : 3400mm*1750mm*750mmL*W*H : 3600mm*1750mm*750mmL*W*H : 3400mm*2100mm*750mm
Cargo plate thicknessBottom 8mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 6mm
Steering wheelHydraulic Power SteeringHydraulic Power SteeringHydraulic Power SteeringHydraulic Power SteeringHydraulic Power SteeringHydraulic Power Steering
Cargo volume1.6 m32.2 m32.2 m34.3 m34.7 m35 m3
