3 Ton Underground Mining Trolley Locomotive

This 3 ton electric locomotive is generally suitable for small mines as auxiliary transportation tools or main traction transportation tools.

Send Inquiry →
CJY10 Ton Underground Mining Trolley Locomotive
3 Ton Underground Mining Trolley Locomotive uses cables to provide energy for the locomotive. After the high-voltage alternating current is stepped down and rectified by the transformer the positive pole is connected to the cable and the negative pole is connected to the track. The current flows into the locomotive through the cable that is in contact with the pantograph and then flows through the automatic air switch controller and resistance box and finally enters the traction motor to drive the motor to run. The motor drives the wheels to rotate through the transmission device and uses the friction between the wheels and the rail surface to make the locomotive move. The current finally flows out of the motor and flows back to the transformer through the track.

Video



Hot Tags: 3 ton underground mining trolley locomotive, China, manufacturers, suppliers, factory, customized, price

←No Information

7 Ton Underground Mining Trolley Locomotive→

Related Products
Model CJY3/6、7、9G(B)
Weight 3 ton
Track gauge 600、762 or 900mm
Traction force 5.74kN
Max traction force 7.36kN
Speed 7.5km/h
Dc voltage 250V
Motor power 6.5kW×2/ 7.5kw*2
Dimensions Length 2750mm
Width 940、1082 or 1220mm
Height 1550mm
Wheelbase 850 mm
Wheel diameter Φ520 mm
working height of Pantograph 1800~2000mm
Min turn radius 6m
Control method Resistance or IGBT
Brake method Mechnical or hydraulic
