Our factory offers underground mining trolley locomotive with factory price and excellent services. We have more than 40 years experience of production and maintenance, covering the market of South America and Africa. We are looking forward be your lo
Our factory offers underground mining trolley locomotive with factory price and excellent services. We have more than 40 years experience of production and maintenance, covering the market of South America and Africa. We are looking forward be your long-term partner in China.
Advantages: no spark ignition danger, suitable for use in mines with gas; no need for wiring, flexible use, suitable for transportation systems with small output, irregular roadway and roadway driving.
 |
Model | CJY3.5/6、7、9G(B) | |
| Weight | 3.5 ton | ||
| Track gauge | 600、762 or 900mm | ||
| Traction force | 5.74kN | ||
| Max traction force | 7.36kN | ||
| Speed | 7.5km/h | ||
| Dc voltage | 250V | ||
| Motor power | 6.5kW×2/ 7.5kw*2 | ||
| Dimensions | Length | 2750mm | |
| Width | 940、1082 or 1220mm | ||
| Height | 1550mm | ||
| Wheelbase | 850 mm | ||
| Wheel diameter | Φ520 mm | ||
| working height of Pantograph | 1800~2000mm | ||
| Min turn radius | 6m | ||
| Control method | Resistance or IGBT | ||
| Brake method | Mechnical or hydraulic | ||
