ZBQ-8 7.5KW Anti-explosion Traction Motor, ZBQ-8 Dc Traction Motor For 5 Ton Battey Locomotive

This ZBQ-8 motor is the anti-explosion type, it applied on the Chinese 5 ton explosion-proof battery locomotive.

CJY10 Ton Underground Mining Trolley Locomotive

ZBQ-8 Mining explosion-proof DC traction motor for 5 ton flame-proof battery locomotive

The motor is applied as the power motor of flame-proof battery locomotive of Model CTY5-6.7.9/90, and suitable for the place with methane and coal gas explosive mixture. It is designed with advanced technique, and has features of high performance and reliable operation capability. Its technical-economic index has reached the level of similar products in Japan, America and other industrially advanced countries.

Motor Video





Hot Tags:
Motor Power 7.5Kw
Voltage 84V
Current 111A
Rotating speed 1130r/min
Max Current 222A
Max Rotating 2400r/min
Structural type Horizontal
Working rating S2-60MIN
Excitation mode excitation
Insulation grade F or H
Type of cooling IC40
Weight 170KG
