10 Ton Explosion-proof Locomotive

The engine casing is processed by seamless steel tubes, specially developed for mine conditions, resistance to moisture and earthquakes.

CJY10 Ton Underground Mining Trolley Locomotive

Product Advantage

All gearbox gears are made of 40CrMnTi heat treatment process high strength and impact resistance.

The engine casing is processed by seamless steel tubes specially developed for mine conditions resistance to moisture and earthquakes.

The steel wheel is cast in manganese steel wear resistant and durable.

The external structure of the locomotive is screwed in for ease of maintenance.



Battery-powered locomotives are designed for horizontal rail transport especially in mines and enclosed spaces. They are also intended for use in potentially explosive environment with coal dust and methane in volume up to 1.5 %. They can work on slopes of rail lines up to 35‰ with track gauge from 500 to 1060 mm at ambient temperatures from -20°C to +40°C.

Locomotive Avantage Please Click: Locomotive Advantages.


Operation video


Hot Tags:
Technical Specification

Model CTY(L)10/679G
Dead-weight 10t
Track gague 600762 or 900mm
Tracktion force 11.18kN 12.83kN
Speed 6.2km/h 7.5 km/h 7.8 km/h
Max traction 19.62kN
Battery device Voltage 110V 132V 140V 144V
Capacity 440Ah
Motor power 11kW×2 15kW×2
dimensions Lenght 4430mm 4250mm
Width 105012121350mm
Height 1600mm 1600mm
Wheel base 1100mm 1150mm
Wheel diameter Φ680mm Φ680mm Φ600mm
Min turn radius 7m
Controlling way Resistence or IGBT or AC Converter
Brake way Mechnical brake or air brake
